Waveshare ESP32-C6 Touch LCD 1.47 Development Board
Rs 5,200.00Rs 5,500.00 (-5%)
Quick Info :
- Controller: ESP32-C6
- Display: 1.47-inch Touch LCD
- Connectivity: Wi-Fi 6, Bluetooth 5, Zigbee
- Memory: 8MB Flash, 512KB SRAM
- Applications: IoT, HMI, AIoT
The Waveshare ESP32-C6 Touch LCD 1.47 is a compact and powerful microcontroller development board designed for rapid prototyping of Human-Machine Interface (HMI) and Internet of Things (IoT) applications. At its core is the high-performance ESP32-C6FH8 chip, featuring a dual RISC-V processor architecture and support for advanced wireless protocols like Wi-Fi 6, Bluetooth 5 (LE), Zigbee, and Thread. The board integrates a vibrant 1.47-inch capacitive touch LCD with a 172×320 resolution, making it ideal for creating interactive graphical user interfaces with frameworks like LVGL. With its onboard TF card slot, USB-C interface, and various peripheral GPIOs, this board provides a comprehensive and secure platform for developing AIoT projects.
Specifications :
- Controller Chip: ESP32-C6FH8
- Processor: Dual-core RISC-V (High-performance up to 160 MHz, Low-power up to 20 MHz)
- Wireless: 2.4GHz Wi-Fi 6, Bluetooth 5 (LE), Zigbee, Thread
- Memory: 8MB Flash, 512KB HP SRAM, 16KB LP SRAM
- Display: 1.47-inch IPS TFT capacitive touch LCD
- Display Resolution: 172 x 320 pixels
- Display Driver: JD9853
- Touch Driver: AXS5106L
- Interfaces: USB Type-C, TF Card Slot, GPIOs
- Dimensions: 36.37 x 20.32 mm (not including USB port)
