TIP42 PNP Bipolar Power Transistor

The TIP42 is a PNP bipolar junction transistor (BJT) designed for general-purpose power switching and amplification applications. With a collector-emitter voltage of -100V and a maximum continuous collector current of -6A, it is ideal for power amplifiers, motor control, voltage regulation, and relay driving circuits.

Specification :

• Transistor Type: PNP Bipolar Junction Transistor (BJT)
• Voltage Ratings:
  • Collector-Emitter Voltage (Vce): -100V
  • Collector-Base Voltage (Vcb): -100V
  • Emitter-Base Voltage (Veb): -5V
• Current Ratings:
  • Continuous Collector Current (Ic): -6A
  • Peak Collector Current (Icm): -10A
• Power Dissipation (Pd): 65W
• Current Gain (hFE): 15 to 75
• Collector-Emitter Saturation Voltage (Vce(sat)): ≤ -2V at Ic = -6A
• Transition Frequency (ft): 3MHz (Typical)
• Operating Temperature Range: -65°C to +150°C
