Arduino Compatible Pro Mini
This Pro Mini board was developed for applications and installations where space is premium and projects are made as permanent set ups. Small, available in 3.3 V and 5 V versions, powered by ATmega328.
The Arduino Compatible Pro Mini is a microcontroller board based on the ATmega328. It has 14 digital input/output pins (of which 6 can be used as PWM outputs), 6 analog inputs, an on-board resonator, a reset button, and holes for mounting pin headers. A six pin header can be connected to an FTDI cable.
Currently available board is 5V model. Call us on 0767658217 for more information
- Microcontroller: ATmega328
- Board Power Supply: 3.35 -12 V (3.3V model) or 5 – 12 V (5V model)
- Circuit Operating Voltage: 3.3V or 5V (depending on model)
- Digital I/O Pins: 14
- PWM Pins: 6
- UART: 1
- SPI: 1
- I2C: 1
- Analog Input Pins: 6
- External Interrupts: 2
- DC Current per I/O Pin: 40 mA
- Flash Memory: 32KB of which 2 KB used by bootloader *
- SRAM: 2 KB *
- EEPROM: 1 KB *
- Clock Speed: 8 MHz (3.3V versions) or 16 MHz (5V versions)
