74LS164 Shift Register IC
Rs 80.00
Quick Info :
- Logic Type : 8-bit serial-in, parallel-out shift register
- Package Type : DIP-14, SOIC-14
- Operating Voltage : 4.75V to 5.25V
- Maximum Clock Frequency : 25MHz
- Low Power Consumption : Typical 16mA at 5V
- Propagation Delay : 18ns
Frequently Bought Together
- This item: 74LS164 Shift Register IC(Rs 80.00)
- 7432 Quad 2-Input OR Gate(Rs 65.00)
- SN74LS156 Decoder(Rs 120.00)
The 74LS164 is a high-speed 8-bit serial-in, parallel-out shift register IC designed for data storage, transfer, and display driving applications. It features two serial data inputs (A & B) with an AND-gated input stage, allowing flexibility in data entry.
Specification :
- Logic Type : 8-bit serial-in, parallel-out shift register
- Package Type : DIP-14, SOIC-14
- Operating Voltage : 4.75V to 5.25V
- Maximum Clock Frequency : 25MHz
- Low Power Consumption : Typical 16mA at 5V
- Propagation Delay : 18ns
- Serial Data Inputs : 2
- Output Type : Buffered
- Clear Input : Active-low reset function
- Operating Temperature : 0°C to 70°C
