60W Soldering Iron Adjustable Temperature with Display

60W Digital Soldering Iron Adjustable Temperature with Display

Specifications :

• Type: Adjustable Temperature Digital Display Electronic Soldering Iron
• Material: ABS Shell, Electric Parts, Rubber Sleeve, Brass Soldering Tip
• Dimensions: 19.5cm (Length)*2.5cm (Diameter)
• Color: Black
• Power: 60 Watt.
• Heater Type: Ceramic Heater
• Adjustable Temperature Range: 200℃~500℃/392℉~932℉
• Heat Up Time: 180 Seconds
• Input Voltage: AC 100V~AC 240V/50Hz~60Hz
• Plug Type of Power Cord: US Plug

Welding Temperature:

In the normal welding state, directly press the increase/decrease button to adjust the temperature, and the actual set temperature can be displayed after the button is released for 2 seconds. (Press the “+” button to increase, press the “-” button to decrease by 1 degree, press and hold to continuously and quickly heat/decrease)

Temperature Calibration:

Example: The soldering iron is set at 350 degrees, and the measured temperature is 355 degrees. Press and hold the “+/-” button for 2 seconds at the same time, the screen number flashes, press “+/-” to enter the actual test temperature (at this time directly enter 355 degrees, the system will automatically exit after 5 seconds after setting, and then enter Normal working status. (The correction range is plus or minus 99 units, beyond this range it is no longer supported)

Password Setting:

Press and hold the “+” key, then turn on the power, enter “—“, press the “+” key to enter the original password “000”, (the “-” key is the shift key at this time), press and hold the “key for 2 seconds to enter the mode state; “1” mode is the direct exit key, “2” mode is to modify the new password (enter 2 mode and display “—“, enter the password directly, press and hold the “-” key for 2 seconds, and then enter the normal working state. Note: the new password function can only take effect when the power is turned on again ),If the password is forgotten, press and hold the “+” key, then turn on the power, enter “—“, enter 123, press the “-” key and then enter 321, press and hold the “-” key for 2 seconds to restore the initial password ( 000)

Package Include:

• 1 x 60W Digital Soldering Iron Adjustable Temperature Ceramic Heater
• 1 x Heat resistive Rubber Sleeve
• 1 x User Manual
