10K Potentiometer

Rs 40.00

Out of stock

Quick Info :

  • 10K Ohm
  • Linear taper, carbon film type
  • Single-Turn

SKU: PAF01 Categories: ,

An adjustable potentiometer can open up many interesting user interfaces. Turn the pot and the resistance changes. Connect VCC to an outer pin, GND to the other, and the center pin will have a voltage that varies from 0 to VCC depending on the rotation of the pot. Hook the center pin to an ADC on a microcontroller and get a variable input from the user!

This pot has a 1/4″ mounting diameter and has a 10K linear taper.

Specifications :

  • 10K Ohm
  • Linear taper, carbon film type
  • Single-Turn
  • Mountable through a panel and comes with mounting hardware
  • Can be soldered to PCB with pins on 0.2″ centers
  • Fit standard knobs designed for a 6mm diameter shaft.
