Terminal Connector With Right Angle PCB Base 2-12 Pin

This Pluggable PCB Terminal Block is an essential component for industrial control and embedded systems, offering a secure, modular solution for wire-to-board connections. The right-angle body orientation and 5.08mm pitch design allow for efficient, compact layouts on your printed circuit board, reducing space usage and wire strain. Available in configurations ranging from 2-pin up to 12-pin (variable product), the female plug uses a reliable screw clamp mechanism to ensure wires are fastened securely, while the male header is soldered onto the PCB. This system allows for quick disconnection and maintenance without unwiring the entire circuit.

Specification :

• Product Type: Pluggable Terminal Block (Plug/Socket Set)
• Pin Pitch (Spacing): 5.08mm
• Number of Positions (Poles): 2/3/4/5/6/7/8/9/10/12 Pins
• Body Orientation: Right Angle (Male PCB base)
• Termination Method: Screw Clamp (Female Plug) / Solder (Male Header)
• Current Rating: Typically 15A
• Voltage Rating: 300V AC/DC
• Wire Gauge Supported: 28 AWG to 12 AWG
